OVERVIEW
Seal the original S tronic transmission oil pan
0CK-321-371-A is the Genuine VW/Audi molded gasket for the specified transmission oil pans. Its perimeter profile follows the original pan and housing to seal the joint when installed using the prescribed procedure.
The correct pan gasket depends on the transmission and pan design. An engine or model badge alone does not identify the transmission sealing arrangement, and a gasket for a different automatic gearbox is not interchangeable.
Technical details
- Complete factory number: 0CK-321-371-A.
- Factory specification: factory transmission oil pan perimeter gasket, complete revision A.
- Design: molded flexible gasket with the original perimeter profile and locating features.
- Quantity supplied: one individual pan gasket.
One gasket is supplied. Transmission pan, filter, fluid, drain plug, bolts and other seals are separate. This is a dry gasket and does not include transmission fluid or service chemicals.
Common reasons to replace
- The pan is removed and the repair procedure requires a new gasket.
- A leak is confirmed at the pan-to-housing joint.
- The original gasket is cut, flattened or displaced.
- The original seal is damaged during an approved transmission repair.
Inspect the pan and housing sealing surfaces for distortion, cracks and corrosion. Identify leaks from neighboring plugs or housings before replacing the gasket. A new seal will not correct a damaged pan or an incorrect fluid level.
Vehicle fitment
Use the confirmed configurations below with the original gearbox and pan identification. S tronic and Tiptronic transmissions use different parts; verify the complete gasket number.
| Vehicle | Model years | Engine | Configuration | Application restrictions |
|---|---|---|---|---|
| Audi Q5 | 2019 | 2.0L TFSI gasoline | Prestige; seven-speed S tronic automatic | Assigned original transmission oil pan gasket. Match gearbox and pan; not an eight-speed Tiptronic gasket. |
| Audi A5 | 2024 | 2.0L mild-hybrid gasoline | quattro Premium Plus; S tronic automatic | Assigned original transmission pan and gasket; identify gearbox and pan before ordering. |
| Audi A6 | 2024 | 2.0L mild-hybrid gasoline | quattro Premium; S tronic automatic | Assigned transmission pan gasket only; excludes different transmission and pan designs. |
Installation guidance
Follow the exact transmission procedure for fluid handling, pan removal and gasket renewal. Clean the sealing surfaces without damaging them, seat the gasket correctly and use the specified bolt sequence and tightening values. Do not add sealant unless the repair procedure calls for it.
Refill with the approved fluid and set its level using the specified temperature-dependent procedure. Perform the prescribed leak, gear-selection and road-test checks before returning the vehicle to service.
Ordering information
One Genuine VW/Audi 0CK-321-371-A transmission oil pan gasket. Confirm original transmission and pan. Fluid, filter, pan and hardware are sold separately.
