APR - Performance ECU Software - 3.0T EA839 V6 (9Y) (Cayenne)

APR ECU Upgrade Stages

Our new suite of MG1 ECU software comes after months of extensive research and development that is typically absent from the aftermarket. Our upgrade makes the engine more powerful and more exciting. We’ve extensively calibrated the system to work flawlessly on the track, while retaining safety routines to protect your engine in the most demanding scenarios. This was all made possible by our engineering team's pursuit of perfection. Development vehicles were outfitted with additional sensors, including turbo shaft speed sensors, thermocouples, transducers, and more, along with our high speed direct RAM logging equipment, to feed valuable data to the team for analysis. After thousands of hours of testing and tuning we created new calibrations that are fine tuned for several octanes and contain hundreds of map changes, with a vast array of safety features built in.

The result of this work is nothing short of astounding. Not only have we increase power, we’ve added many safety routines to ensure the engine and components are protected under demanding scenarios. Additionally we’ve added features to enhance the driving experience.

We’ve recalibrated the exhaust flaps to reduce backpressure and create consistent turbo spool characteristics. Sound characteristics are improved too, especially during free-rev, which sees its limiter raise in park and neutral. We’ve added an optional feature to enable exhaust crackle, which mimics much of the behavior of the RS models without being over-the-top and obnoxious. This enables during free-rev, downshifts, and lifting off the throttle. It’s optimized with exhaust flap actuation, and includes safety routines to ensure component protection. Through proper torque management and ECU code changes, we’ve removed the requirement of a transmission tune to achieve full torque. We’ve optimized launch control for a better take-off and enabled boost building on the line. Additionally we’ve defaulted the start-stop feature to the off position, removed the speed limiter, added left-foot braking or brake-boosting, and configured the ECU to send the correct calibration to the dash for the performance gauges.

To protect the engine and components we’ve spent a considerable amount of time tuning safety routines, some of which were not active from the factory. The ECU will protect the engine should the exhaust flaps fail as back pressure becomes too high. The optional exhaust crackle feature will turn off should components get too hot. The engine has advanced LSPI protection to prevent the engine from damage when being lugged in the tallest gears. Excessive intake air temperature, which is common on a dynamometer, will cause power to reduce to protect the engine. Furthermore more we’ve added and calibrated protection routines for turbocharger pressure ratios, shaft speed, exhaust pressure, intake air temperature, coolant temperature, oil temperature, lambda, fueling system limitations, and more. All of this and more gives us confidence to offer an optional limited powertrain warranty through APR Plus!

Our ECU Upgrades are available in multiple configurations. Installation of additional performance hardware, such as an intercooler or intake systems, may provide further performance improvements.
