Genuine VW/Audi

Alarm System Bracket Socket Head Bolt

Alarm System Bracket Socket Head Bolt

SKU:N-101-153-07

Regular price $0.92 USD
Regular price $0.92 USD Sale price $0.92 USD
Sale Sold out
Shipping calculated at checkout.
In stock
Quantity
View full details

OVERVIEW

Genuine Socket Head Mounting Bolt M6 × 12mm

The N-101-153-07 Genuine VW/Audi socket head combination bolt is cataloged at position 8 in the original anti-theft alarm bracket arrangement on the matched Audi Q7 applications below. It provides the specified threaded attachment hardware for that mounting position. This listing supplies one bolt.

Technical Details

  • OEM part number: N-101-153-07.
  • Thread size: M6.
  • Nominal bolt length: 12 mm.
  • Drive: internal hexagon/socket head.
  • Construction: combination bolt with the associated seating washer visible in the original photograph.
  • Matched catalog position: 8 in anti-theft alarm illustration 951-400.
  • Equipment requirement for the Q7 alarm application: PR-7AN, anti-theft alarm with backup horn and towing protection.
  • Quantity supplied: one bolt; the matched diagram specifies one at this position.

The bolt is service hardware for a particular bracket arrangement, rather than an electrical component. The same standard fastener may appear at other locations in the wider parts catalog, but those uses require their own application check. Do not assume that all M6 alarm, horn or bracket mounting positions use a 12 mm socket head combination bolt.

Additional confirmed cooling-system application

On the listed 2007 A4 2.0T installation, this bolt appears at position 35 beside the turbocharger coolant feed pipe and its heat insulation. Retain the original shield and mounting arrangement so the pipe and surrounding components maintain their designed clearance. A missing or damaged fastening bolt can leave the assigned shield or attachment insecure; inspect the shield, bracket and receiving threads before replacing the hardware. This bolt does not seal a coolant connection, and installing it will not repair a leaking pipe or damaged sealing ring.

Common Reasons to Replace

  • The socket is rounded or damaged, making reliable removal or tightening difficult.
  • Threads are cross-threaded, stripped or affected by corrosion.
  • The original bolt or its associated seating hardware is missing during bracket service.
  • Incorrect replacement hardware has been installed and does not match the required mounting position.
  • Inspection during alarm-system or nearby bracket service identifies a damaged fastener that needs renewal.

Inspect the bracket and receiving threads before installing replacement hardware. A new bolt does not repair a cracked mounting bracket or damaged threaded hole. An alarm fault, intermittent siren operation or warning message also requires diagnosis of the electrical system; this mechanical fastener does not replace the siren, control module or wiring.

Vehicle Fitment

The table applies to the original bracket position and specified alarm equipment. Match the vehicle's equipment code and mounting arrangement before ordering. Vehicles with different alarm equipment or a different hardware position require a separate part-number check.

Vehicle Model years Engine Configuration Application restrictions
Audi Q7 2007–2009 3.6L V6 gasoline 4L SUV with original anti-theft alarm bracket; PR-7AN; quattro; no transmission-specific restriction at this bracket position Anti-theft alarm system illustration 951-400, position 8, M6 × 12 mm. PR-7AN: anti-theft alarm with backup horn and towing protection. Match the original bracket arrangement including 7L0-971-262. Not a general fit for every alarm or horn mounting point.
Audi Q7 2007–2009 4.2L V8 gasoline 4L SUV with original anti-theft alarm bracket; PR-7AN; quattro; no transmission-specific restriction at this bracket position Anti-theft alarm system illustration 951-400, position 8, M6 × 12 mm. PR-7AN: anti-theft alarm with backup horn and towing protection. Match the original bracket arrangement including 7L0-971-262. Not a general fit for every alarm or horn mounting point.
Audi Q7 2009 3.0L V6 TDI diesel 4L SUV with original anti-theft alarm bracket; PR-7AN; quattro; no transmission-specific restriction at this bracket position Anti-theft alarm system illustration 951-400, position 8, M6 × 12 mm. PR-7AN: anti-theft alarm with backup horn and towing protection. Match the original bracket arrangement including 7L0-971-262. Not a general fit for every alarm or horn mounting point.
Audi A4 2007 2.0L turbo FSI gasoline inline-four; BWT B7 sedan / Avant; FWD or quattro; original turbocharger coolant-pipe shielding; Match original six-speed manual, CVT or quattro Tiptronic configuration Cooling-system diagram position 35, M6 × 12, beside the original 06D-121-497-A turbo coolant feed pipe and 06D-133-833-A heat insulation. Confirm original shield and mounting point. This is fastening hardware, not a coolant pipe, banjo bolt or fluid seal.

Installation and Ordering Notes

Compare the original part number, thread diameter, length, drive and seating arrangement. Use the vehicle-specific repair procedure for access, assembly and tightening. No universal torque, thread treatment or additional washer arrangement is specified here because those details depend on the exact mounting assembly.

The alarm siren, brackets, connectors, wiring and other fasteners are sold separately. This listing contains one mechanical bolt and no electronic components. The seven-image gallery repeats the available original photograph with distinct descriptive metadata. Repeated images show the same piece and do not indicate a multipack.
