OVERVIEW
Factory hardware for the specified transmission attachment
N-105-155-02 is a Genuine VW/Audi M12 x 40 socket-head flange bolt with an internal multipoint drive. It is used at the assigned original transmission-assembly fastening point in the five-speed automatic applications below.
The transmission assembly uses bolts of several lengths and head types. Matching the original fastener location and complete part number helps preserve the intended thread engagement and head clearance; a similar-looking M12 bolt is not sufficient identification.
Technical details
- Complete factory number: N-105-155-02.
- Factory specification: M12 x 40 mm, internal multipoint drive.
- Design: Socket head with integral collar for the original bearing surface.
- Quantity supplied: one individual bolt; transmission, dowel sleeves and other attachment hardware are not included.
M12 x 40 identifies nominal diameter and fastener length. No unverified thread pitch, drive-bit size, tightening torque, shipping weight or package size is assigned.
Common reasons to replace
- Damaged multipoint recess that prevents secure tool engagement.
- Damaged threads, a bent shank or an impaired collar seating surface.
- Missing or incorrect hardware found during transmission removal or installation.
Inspect the receiving threads, dowel alignment and mating surfaces before assembly. Replacing one bolt does not correct a damaged housing, worn mount or misaligned transmission.
Vehicle fitment
Match the five-speed conventional automatic transmission and original fastening point below. These entries do not include a four-speed automatic, a manual transmission or a DSG.
| Vehicle | Model years | Engine | Configuration | Application restrictions |
|---|---|---|---|---|
| Volkswagen Jetta | 2003 | 1.8L turbocharged gasoline | Mk4 sedan, FWD; 5-speed Tiptronic automatic, PR G0F | Original transmission-assembly fastening point specifying N-105-155-02, M12 x 40. Not 4-speed automatic, manual or DSG hardware. |
| Volkswagen Jetta Wagon | 2003 | 1.8L turbocharged gasoline | Mk4 wagon, FWD; 5-speed Tiptronic automatic, PR G0F | Original M12 x 40 transmission-assembly fastener location; verify gearbox identity and full number. Excludes 4-speed, manual and DSG. |
Installation guidance
Support the engine and transmission according to the factory repair procedure. Align the components on their specified dowels before starting bolts; do not draw a misaligned assembly together by tightening its hardware.
Use the correct multipoint tool and the prescribed tightening sequence, torque and replacement instructions for the exact joint. Check seating, support and operating clearances after installation.
Ordering information
New and unused inventory. Sold individually as N-105-155-02. Confirm the original full number, transmission identification and required quantity before ordering.
