OVERVIEW
Original screw for the driver-assistance module bracket
N-106-572-01 is the Genuine VW/Audi screw cataloged for the driver-assistance control-module bracket on the confirmed electric Audi applications below. It retains the assigned bracket at its original mounting point.
Fasteners with a similar diameter can have different lengths, head forms and clamping requirements. Match the original factory number and assigned joint rather than choosing a bolt by appearance alone.
Technical details
- Complete factory number: N-106-572-01.
- Factory specification: driver-assistance module bracket screw N10657201.
- Design: recessed-drive pan head with coarse screw thread.
- Quantity supplied: one individual screw.
This listing supplies one individual screw. The archive reference photo shows multiple examples of the same hardware, rather than a multi-piece kit. The control module, bracket and wiring are separate components.
Common reasons to replace
- The original bolt is missing after component service.
- Threads are damaged or will not engage correctly.
- The drive head is rounded or otherwise damaged.
- Corrosion or deformation makes the original fastener unsuitable for reuse.
Inspect the bracket and receiving mounting feature before installation. A damaged bracket or faulty assistance system requires separate diagnosis; replacing a mounting screw does not calibrate or repair an electronic module.
Vehicle fitment
Use only at the assigned factory fastening position on the listed applications. These vehicle entries do not establish compatibility with every fastening point on the vehicle.
| Vehicle | Model years | Engine | Configuration | Application restrictions |
|---|---|---|---|---|
| Audi e-tron Sportback | 2020 | Battery electric | quattro; Premium Plus | Driver-assistance control-module bracket screw at original N10657201 position; confirm bracket configuration. |
| Audi Q8 e-tron Sportback | 2024 | Battery electric | quattro; Premium | Assigned driver-assistance module bracket screw only; original bracket required. |
Installation guidance
Follow the vehicle-specific control-module and bracket service procedure, including electrical isolation instructions where required. Locate the bracket correctly and use the specified tightening torque. If the repair procedure requires calibration or basic settings after component disturbance, complete those steps.
Confirm that the bracket and module are properly secured and wiring is routed correctly. Check the relevant assistance-system operation and fault memory as directed by the repair procedure.
Ordering information
One individual genuine screw. Matching clips, brackets, trim, electronic modules and other assembly components are separate. Confirm VIN and original hardware number.
