OVERVIEW
Original oval-head hardware for partition-net supports
N-903-659-16 is a Genuine VW/Audi M8 x 22 oval-head bolt with an internal hex drive. Its confirmed applications below secure the specified original partition-net support or eyelet attachment.
The head profile and bearing arrangement suit the assigned mounting point. Cargo-area partitions, roller covers and tie-down hardware can appear together in a catalog, but their fasteners serve different joints; match the original complete number rather than selecting by appearance.
Technical details
- Complete factory number: N-903-659-16.
- Factory specification: M8 x 22 mm oval-head internal-hex bolt.
- Design: Rounded head with recessed six-sided drive and broad bearing surface.
- Quantity supplied: one individual bolt.
The full revision N-903-659-16 identifies the supplied fastener. This listing supplies one bolt, not a support bracket, net partition or complete set of mounting screws.
Common reasons to replace
- A damaged hex drive that prevents controlled tightening or removal.
- Damaged threads, a bent shank or a compromised head seating surface.
- Missing original hardware or an incorrect substitute discovered during partition support service.
Inspect the support eyelet, bracket and receiving thread. A partition that will not latch or stays loose can have a worn locking mechanism or damaged support, which a replacement bolt alone will not repair.
Vehicle fitment
These entries require the original partition-net support arrangement and the specified wagon or SUV body. Confirm the exact attachment before selecting the bolt.
| Vehicle | Model years | Engine | Configuration | Application restrictions |
|---|---|---|---|---|
| Audi Q5 | 2011–2017 | 2.0L turbocharged gasoline | 8R SUV, quattro, original net-partition mounting arrangement; 8-speed automatic | Original partition-net support/eyelet attachment requiring N-903-659-16. Confirm the exact original support and complete number. Excludes vehicles without this mounting arrangement and 2018-on FY generation. |
| Audi A4 Avant | 2009–2012 | 2.0L turbocharged gasoline | B8 wagon, quattro, original net-partition mounting arrangement; 6-speed automatic for 2009–2010; 8-speed automatic for 2011–2012 | Original partition-net support/eyelet mounting point specifying N-903-659-16. Confirm exact attachment and complete bolt number; not a sedan fitment claim. |
| Audi A4 allroad | 2013–2016 | 2.0L turbocharged gasoline | B8 wagon, quattro, original net-partition mounting arrangement; 8-speed automatic | Original net-partition support/eyelet attachment requiring N-903-659-16. Confirm the factory partition and exact mounting point before ordering. |
Installation guidance
Support the mounting component and preserve the original spacer, bracket and trim arrangement. Start the bolt by hand and follow the factory tightening procedure for the vehicle and attachment.
Check support security and partition engagement after assembly. Replace damaged brackets or locking components where required and verify the intended clearance to adjacent trim.
Ordering information
New and unused inventory. Sold individually as N-903-659-16. Confirm VIN, complete factory number, original mounting arrangement and required quantity before ordering.
