OVERVIEW
Factory flat-head bolt for the original belt tensioner
N-911-894-01 is a Genuine VW/Audi M10 x 60 flat-head bolt with an internal multipoint drive. It secures the specified original belt-tensioner or damper attachment in the confirmed applications below.
The belt-drive arrangement uses several bolt and pulley types. The correct flat-head profile, nominal length and original joint must match; this individual fastener is not a tensioner assembly and does not include a pulley, bearing or belt.
Technical details
- Complete factory number: N-911-894-01.
- Factory specification: M10 x 60 mm flat-head internal-multipoint bolt.
- Design: Low head profile with recessed multipoint drive and threaded shank.
- Quantity supplied: one individual bolt.
M10 x 60 gives nominal thread diameter and fastener length. No unverified thread pitch, bit size, strength class, tightening torque or shipping measurement is stated.
Common reasons to replace
- Damaged multipoint recess that prevents secure tool engagement.
- Damaged threads, a bent shank or an impaired head seating surface.
- Missing or incorrect hardware found during belt or tensioner service.
Belt noise, poor tracking or tensioner movement requires diagnosis of the belt, pulley bearings, damper and mounting surfaces. A new bolt alone does not repair a worn tensioner or bearing.
Vehicle fitment
Match the model, engine and specified original belt-tensioner location below. Revisions to an adjacent tensioner do not automatically establish a different bolt application.
| Vehicle | Model years | Engine | Configuration | Application restrictions |
|---|---|---|---|---|
| Volkswagen Touareg Hybrid | 2013 | 3.0L supercharged gasoline-electric hybrid | 7P SUV, 4Motion; 8-speed automatic | Original belt-tensioner/damper fastening point specifying N-911-894-01; TC6 engine branch. Match the exact tensioner and complete hardware number. |
| Audi Q5 | 2014 | 3.0L supercharged V6 gasoline, PR TC6 | 8R SUV, quattro; 8-speed automatic | Original belt-tensioner/damper fastening point specifying N-911-894-01; TC6 branch only; excludes 2.0L and TDI. Match the exact tensioner and complete hardware number. |
| Audi A6 | 2014 | 3.0L supercharged V6 gasoline, PR TC6 | C7 sedan, quattro; 8-speed automatic | Original belt-tensioner/damper fastening point specifying N-911-894-01; TC6 branch only; not 2.8L foreign-market or diesel hardware. Match the exact tensioner and complete hardware number. |
| Audi Q7 | 2014 | 3.0L supercharged V6 gasoline | 4L SUV, quattro; 8-speed automatic | Original belt-tensioner/damper fastening point specifying N-911-894-01; Original gasoline belt-drive branch; excludes TDI. Match the exact tensioner and complete hardware number. |
Installation guidance
Relieve belt tension using the prescribed procedure and support the affected component. Preserve the specified spacers and mounting pieces, then start the correct bolt by hand.
Use the proper multipoint tool fully seated in the recess and follow the factory replacement rules and tightening specification. Verify belt routing, pulley alignment and clearance before operating the engine.
Ordering information
New and unused inventory. Sold individually as N-911-894-01. Confirm the original complete number and quantity required for the exact belt-drive repair.
