OVERVIEW
Original oval-head hardware for the assigned door assembly
WHT-001-241 is a Genuine VW/Audi M8 x 14 oval-head combination bolt with an internal hex drive. It replaces the specified original fastener in the wagon door assemblies listed below.
Door assemblies use different hardware for hinges, locating points, reinforcements and other attachments. Confirm this exact number at the original fastening position; a short M8 bolt is not automatically interchangeable with a neighboring fastener.
Technical details
- Complete factory number: WHT-001-241.
- Factory specification: M8 x 14 mm oval-head internal-hex combination bolt.
- Design: Rounded head with washer-style bearing arrangement and recessed six-sided drive.
- Quantity supplied: one individual bolt; door, reinforcement, hinge, glass and other hardware are not included.
The nominal specification describes the bolt dimensions. No unverified drive-bit size, thread pitch, strength class, torque, shipping weight or package size is stated.
Common reasons to replace
- A damaged hex recess that prevents secure tool engagement.
- Damaged threads or an impaired head seating surface found during door assembly service.
- Missing hardware or an incorrect substitute discovered during repair.
Inspect the attached part, receiving threads and surrounding door structure. Rattles or poor door operation can have other causes; replacing the bolt alone does not repair a distorted bracket, damaged attachment or worn hinge.
Vehicle fitment
Match the body generation, wagon configuration and original VIN restriction below. This is hardware for the specified door assembly position, not a universal hinge bolt.
| Vehicle | Model years | Engine | Configuration | Application restrictions |
|---|---|---|---|---|
| Audi allroad | 2001–2005 | 2.7L twin-turbocharged V6 gasoline | C5 wagon, quattro, PR K8X; Original configuration | Original rear-door assembly fastener; VIN from 4B-1-100001, production 2001-02 through 2005-08. Earlier M8 x 14 hardware uses a different number. |
| Audi allroad | 2004–2005 | 4.2L V8 gasoline | C5 wagon, quattro, PR K8X; Original configuration | Original rear-door assembly bolt at position specifying WHT-001-241. Production through 2005-08; confirm full original number. |
| Audi A4 Avant | 2005 | 1.8L turbocharged or 3.0L V6 gasoline | B6 wagon, quattro, PR K8D; Original configuration | Original rear-door assembly hardware. B6 chassis only, VIN through 8E-5-400000; excludes later B7 hardware unless independently confirmed. |
| Audi S4 Avant | 2005 | 4.2L V8 gasoline | B6 wagon, quattro, PR K8D; Original configuration | Original rear-door assembly hardware; B6 only, VIN through 8E-5-400000. |
| Audi A6 Avant | 2010 | 3.0L supercharged V6 gasoline | C6 wagon, quattro, PR K8D; Original configuration | Original rear-door side-reinforcement/door assembly fastener calling for WHT-001-241; not a hinge locating bolt. |
Installation guidance
Follow the factory door assembly repair procedure and support affected components before removing hardware. Preserve any specified washer and spacer order and start the correct bolt by hand.
Use a fully seated hex tool and the tightening method for the exact joint. Complete the required door alignment, attachment and operating checks after service.
Ordering information
New and unused inventory. Sold individually as WHT-001-241. Confirm the complete factory number, body configuration and required quantity before ordering.
